Chapter 3 Ethernet Configuration
© National Instruments Corporation 3-7 GPIB-ENET/100 for Windows Me/98/95
Tip
To find out the network settings for your computer, perform the following steps:
♦
Windows Me/98
1. Open a DOS prompt.
2. Type
IPCONFIG
.
3. Press <Enter>.
If you need more information, you can run
ipconfig
with the
/all
option
by typing
IPCONFIG /all
at the DOS prompt. This shows you all of the
settings for the computer. Make sure you use the settings for the Ethernet
adapter you are using to communicate with the GPIB-ENET/100.
♦
Windows 95
1. Open a DOS prompt.
2. Type
WINIPCFG
.
3. Press <Enter>.
4. Select the Ethernet adapters you are using to communicate with the
GPIB-ENET/100 from the drop-down list.
Verifying the Hostname
The NI Ethernet Device Configuration utility automatically verifies that the
hostname for each DHCP-enabled device matches the DNS entry for the
assigned IP address. This verification process automatically occurs when
you either run the utility or click Refresh. The utility alerts you as shown
in Figure 3-4 if it detects a problem with the network settings.
Figure 3-4.
Hostname Verification Error Detected

National Instruments GPIB Series Specifications

General

Bus Interface	GPIB (IEEE 488)
Operating Systems Supported	Windows, Linux, macOS
Weight	Varies by model
Form Factor	PCI, PCIe, USB
Number of GPIB Ports	1
Software Support	NI-488.2 driver
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Power Requirements	Varies by model (e.g., USB bus-powered or external power)
Dimensions	Varies by model
Data Transfer Rate	Up to 8 MB/s
