Chapter 7 Counters

X Series User Manual 7-48 ni.com

Table 7-9. X Series PCI Express/PXI Express/USB Mass Termination Device Default

NI-DAQmx Counter/Timer Pins

Counter/Timer Signal Default Connector 0 Pin Number (Name)

CTR 0 SRC 37 (PFI 8)

CTR 0 GATE 3 (PFI 9)

CTR 0 AUX 45 (PFI 10)

CTR 0 OUT 2 (PFI 12)

CTR 0 A 37 (PFI 8)

CTR 0 Z 3 (PFI 9)

CTR 0 B 45 (PFI 10)

CTR 1 SRC 42 (PFI 3)

CTR 1 GATE 41 (PFI 4)

CTR 1 AUX 46 (PFI 11)

CTR 1 OUT 40 (PFI 13)

CTR 1 A 42 (PFI 3)

CTR 1 Z 41 (PFI 4)

CTR 1 B 46 (PFI 11)

CTR 2 SRC 11 (PFI 0)

CTR 2 GATE 10 (PFI 1)

CTR 2 AUX 43 (PFI 2)

CTR 2 OUT 1 (PFI 14)

CTR 2 A 11 (PFI 0)

CTR 2 Z 10 (PFI 1)

CTR 2 B 43 (PFI 2)

CTR 3 SRC 6 (PFI 5)

CTR 3 GATE 5 (PFI 6)

CTR 3 AUX 38 (PFI 7)

CTR 3 OUT 39 (PFI 15)

CTR 3 A 6 (PFI 5)

CTR 3 Z 5 (PFI 6)

CTR 3 B 38 (PFI 7)

FREQ OUT 1 (PFI 14)
