Chapter 7 Counters
© National Instruments 7-49 X Series User Manual
Table 7-10. X Series USB Screw Terminal Device Default NI-DAQmx Counter/Timer
Pins
Counter/Timer Signal Default Pin Number (Name)
CTR 0 SRC 81 (PFI 8)
CTR 0 GATE 83 (PFI 9)
CTR 0 AUX 85 (PFI 10)
CTR 0 OUT 89 (PFI 12)
CTR 0 A 81 (PFI 8)
CTR 0 Z 83 (PFI 9)
CTR 0 B 85 (PFI 10)
CTR 1 SRC 76 (PFI 3)
CTR 1 GATE 77 (PFI 4)
CTR 1 AUX 87 (PFI 11)
CTR 1 OUT 91 (PFI 13)
CTR 1 A 76 (PFI 3)
CTR 1 Z 77 (PFI 4)
CTR 1 B 87 (PFI 11)
CTR 2 SRC 73 (PFI 0)
CTR 2 GATE 74 (PFI 1)
CTR 2 AUX 75 (PFI 2)
CTR 2 OUT 93 (PFI 14)
CTR 2 A 73 (PFI 0)
CTR 2 Z 74 (PFI 1)
CTR 2 B 75 (PFI 2)
CTR 3 SRC 78 (PFI 5)
CTR 3 GATE 79 (PFI 6)
CTR 3 AUX 80 (PFI 7)
CTR 3 OUT 95 (PFI 15)
CTR 3 A 78 (PFI 5)
CTR 3 Z 79 (PFI 6)
CTR 3 B 80 (PFI 7)
FREQ OUT 93 (PFI 14)
