Appendix A Device-Specific Information
© National Instruments A-5 X Series User Manual
NI 6321/6341
The following sections contain information about the NI PCIe-6321,
NI PCIe/PXIe-6341, and NI USB-6341 devices.
NI 6321/6341 Pinouts
Figure A-2 shows the pinout of the NI PCIe-6321 and NI PCIe/PXIe-6341
devices. For a detailed description of each signal, refer to the I/O Connector
Signal Descriptions section of Chapter 3, Connector and LED Information.
