Appendix A Device-Specific Information
© National Instruments Corporation A-79 E Series User Manual
NI DAQPad-6052E BNC Pinout
Figure A-68 shows the NI DAQPad-6052E BNC device pinout.
Note Some hardware accessories may not yet reflect the NI-DAQmx terminal names. If
you are using an E Series device in Traditional NI-DAQ (Legacy), refer to Table 1-5,
Terminal Name Equivalents, for the Traditional NI-DAQ (Legacy) signal names.
Figure A-68. NI DAQPad-6052E BNC Device Pinout
For a detailed description of each signal, refer to the
I/O Connector Signal
Descriptions section of Chapter 1, DAQ System Overview.
NI PCI/PXI-6052E
The NI PCI/PXI-6052E are Plug-and-Play, multifunction AI, AO, DIO, and
TIO devices.
The NI PCI/PXI-6052E feature the following:
• 16 AI channels (eight differential) with 16-bit resolution
• Two AO channels with 16-bit resolution
• Eight lines of TTL-compatible DIO
P0.7
P0.6
P0.5
P0.4
P0.3
P0.2
P0.1
P0.0
CTR 1 OUT
D GND
USER 1
AI HOLD COMP
EXT STROBE
AI SENSE
AI GND
PFI 9
PFI 8
PFI 7
PFI 6
PFI 5
PFI 4
PFI 3
PFI 2
PFI 1
D GND
USER 2
FREQ OUT
+5 V
+5 V
D GND
