National Instruments PCI-6035E User Manual

© National Instruments Corporation B-1 E Series User Manual
B
I/O Connector Pinouts
Table corresponds each E Series device to the associated I/O connector
pinouts for that device and compatible accessories.
Table B-1. E Series I/O Connector Pinouts
E Series Device Typical Cable Accessory
NI 6013 SH6868EP Refer to Figure A-4.
SH6850 Refer to Figure B-4.
NI 6014 SH6868EP Refer to Figure A-5.
SH6850 Refer to Figure B-4.
NI DAQPad-6015 — —
NI DAQPad-6015 BNC — —
NI DAQPad-6015 Mass
Termination
— —
NI DAQPad-6016 — —
NI DAQPad-6020E SH6868EP Refer to Figure A-33.
SH6850 Refer to Figure B-4.
NI DAQPad-6020E BNC — —
NI 6023E SH6868EP Refer to Figure A-37.
SH6850 Refer to Figure B-4.
NI 6024E SH6868EP Refer to Figure A-38.
SH6850 Refer to Figure B-4.
NI 6025E SH1006868 Refer to Figure B-2.
SH100100 Refer to Figure A-39.
R1005050 Refer to Figure B-3.
