National Instruments PXIe-4302 User Manual

NI PXIe-4302/4303 and TB-4302/4302C | © National Instruments | 13
Terminal Block Removal
To remove the terminal block, refer to Figure 8 while completing the following steps:
Note The chassis can be powered on or off when removing the terminal block.
1. Loosen the terminal block mounting screw located at the top of the terminal block.
2. To remove the terminal block:
a. Raise the latch release using a flathead screwdriver to disengage the latch.
b. With the latch release raised, grasp the terminal block and pull it away from the
module.
Figure 8. Removing the TB-4302/4302C from the NI PXIe-4302/4303 Module
3. Store the terminal block in an antistatic protective bag.
1 Mounting Screw
2 Latch Release
3 PXIe Controller
4 PXIe Chassis
5 TB-4302/4302C Terminal Block
NI
PXI
e-1
062Q
5
1
2
COO
LING CLEA
RA
NCE
A
ND FAN FIL
TE
R M
A
INTE
N
A
NCE RE
Q
UIRED
. S
E
E
M
A
NUAL.
CO
O
L
I
N
G CL
E
A
R
A
N
CE
A
ND
FA
N
F
ILT
E
R MA
IN
TE
N
A
NC
E
R
E
QU
I
R
E
D
. S
E
E
M
A
N
U
A
L
.
3
4
