Instructions for Use XLTEK Protektor32
18
Electrical Fast Transients /
Bursts
IEC 61000-4-4 ± 2 kV
100 kHz repetition frequency
Surges
Line-to-line (Differential Mode)
IEC 61000-4-5 ± 0,5 kV, ± 1 kV
Surges
Line-to-ground (Common Mode)
IEC 61000-4-5 ± 0,5 kV, ± 1 kV, ± 2 kV
Conducted Disturbances
Induced by RF Fields
IEC 61000-4-6 3 V
0,15 MHz – 80 MHz
6 V in ISM bands between
0,15 MHz and 80 MHz
80 % AM at 1 kHz
Voltage Dips IEC 61000-4-11 100% dip; 0,5 cycle
At 0°, 45°, 90°, 135°, 180°, 225°, 270° and
315°
100% dip; 1 cycle
and
30% dip; 25 cycles (50Hz)
Single phase: at 0°
Voltage Interruptions IEC 61000-4-11 100% dip; 250 cycles (50Hz) /300 cycles (60
Hz)
Table 7 – Patient Coupling Port
Phenomenon
Basic EMC Standard
or Test Method
Immunity Test Levels – Professional
Healthcare Facility Environment
Electrostatic Discharge IEC 61000-4-2 ± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ± 15 kV air
Conducted Disturbances
Induced by RF Fields
IEC 61000-4-6
3 V
0,15 MHz – 80 MHz
6 V in ISM bands between
0,15 MHz and 80 MHz
80 % AM at 1 kHz
Table 8 – Immunity Test Levels - Signal Input / Output Parts Port
Phenomenon
Basic EMC
Standard
Immunity Test Levels – Professional
Healthcare Facility Environment
Electrostatic Discharge IEC 61000-4-2
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ± 15 kV air
Electrical Fast Transients/Bursts IEC 61000-4-4 ± 1 kV
