7. Click OK to save.
To use the head map to set up Referential Channels:
1. Click a location on the headmap to select Input 1. A new channel will appear in the EEG table
with Input 1 set accordingly.
2. Repeat Step 1 until you have added the channels you require to the test.
3. To select the remaining settings for the new channels, right-click column headings or individual
cells to select values for LFF, HFF, Notch, Color, Gain, and Quadrant from the pop-up menus.
See the topic EEG Channel Settings for more information.
4. Click OK to save.
Note that if a referential channel already exists, it will not be added to the table when you
click that location in the head map.
To use the EEG table to set up referential channels:
1. Click the Add button that is located to the right of the EEG table. An empty channel with a red
background will appear in the table.
2. Right-click the Input 1 cell of the new channel and select an EEG electrode location from the
pop-up menu.
3. Repeat Step 1 until you have added the required channels to the test.
4. To select the remaining settings for the new channels, right-click column headings or individual
cells to select values for LFF, HFF, Notch, Color, Gain, and Quadrant from the pop-up menus.
See the topic EEG Channel Settings for more information.
5. Click OK to save.
Setting Up Channels for Custom EEG Locations
Before you set up a channel for a custom EEG electrode location, you need to assign a custom EEG
location in the Electrodes tab. Once this is done, the custom location appears in the pop-up menu when
you right-click an Input 1 cell in the EEG tab.
To set up a channel for your custom EEG electrode location:
1. Click the button to add a new channel to the montage.
2. Right-click the Input 1 column cell and select the custom EEG location you want from the pop-up
menu.
3. Repeat Step 1 to add the required custom channels to the test.
4. To select the remaining settings for the new channels, right-click column headings or individual
cells to select values for LFF, HFF, Notch, Color, Gain, and Quadrant from the pop-up menus.
See the topic EEG Channel Settings for more information.
5. Enter a name for the montage in the Name text box above the head map.
6. Click OK to save.
Custom EEG locations can also be used to set up the EEG montage; however, note that
they will not appear on the EEG tab head map.
