NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-2 Issue 3.2 2014-12-10
Table 4.1: Wiring Lists Provided
Table # Description
Table 4.3 Wiring List - NV5/NV3.5 Transmitter (page 4-2)
Table 4.5 Wiring List - NAE104A & /01 NVE50 Exciter (page 4-11)
Table 4.7 Wiring List - Ac Distribution Assembly (Nautel Part # 206-5150-01) (page 4-13)
Table 4.8 Wiring List - NAA56/01D RF Power Module (page 4-14)
Table 4.2: Connector Mating Information Provided
Table # Description
Table 4.4 Connector Mating Information - NV5/NV3.5 Transmitter (page 4-8)
Table 4.6 Connector Mating Information - NAE104A & /01 NVE50 Exciter (page 4-12)
Table 4.9 Connector Mating Information - NAA56/01D RF Power Module (page 4-15)
Table 4.3: Wiring List - NV5/NV3.5 Transmitter
Source Destination Wire # Colour Size Remarks
P24-1 P24-3 - Capacitor C1, 0.001 uF
P25-1 P25-3 - Capacitor C2, 0.001 uF
U1-6 (+V) U1-4 (-V) - Capacitor C6, 0.47 uF
U2-6 (+V) U2-4 (-V) - Capacitor C7, 0.47 uF
TB1-1B1 TB2-1A1 1 Black 6 3-Ph, 208 (L1A)
TB1-1B2 TB3-1A1 2 Black 6 3-Ph, 208 (L1B)
TB1-2B1 TB2-2A1 3 Black 6 3-Ph, 208 (L2A)
TB1-2B2 TB3-2A1 4 Black 6 3-Ph, 208 (L2B)
TB1-3B1 TB2-3A1 5 Black 6 3-Ph, 208 (L3A)
TB1-3B2 TB3-3A1 6 Black 6 3-Ph, 208 (L3B)
TB1-1B1 TB2-1A1 1 Black 6 3-Ph, 400 (L1A)
TB1-2B1 TB2-3A1 2 Black 6 3-Ph, 400 (L2A)
TB1-3B1 TB3-2A1 3 Black 6 3-Ph, 400 (L3A)
TB1-4B1 TB2-2A1 4 Black 6 3-Ph, 400 (N1A)
