Nautilus E614 Assembly Manual

10
3. Attach the Manual Lift Assembly using the Arm Pivot Rod
Note: Hardware (*) is pre-installed and not on the Hardware Card.
NOTICE: With the Arm Pivot Rod under the straight section of tube near the front, push the Manual Lift Assembly
toward the Frame Assembly and fully tighten hardware. Remove the Arm Pivot Rod after tightening.
Keep fingers away from any pinch opportunities when placing or removing the Arm Pivot Rod.
*
*
7
4

Nautilus E614 Specifications

General

Brand	Nautilus
Model	E614
Category	Elliptical Trainer
Language	English
