Nautilus E614 Assembly Manual

6
A decal has been applied to all right (“ R ”) and left (“ L ”) parts to assist with assembly.
Item Qty Description Item Qty Description
1 1 Console 12 1 Left Leg
2 1 Shroud Cap 13 1 Frame
3 1 Console Mast 14 1 Front Stabilizer
4 1 Arm Pivot Rod 15 1 Right Leg
5 1 Static Handlebar 16 1 Upper Shroud
6 1 Water Bottle Holder 17 1 Right Pedal
7 1 Manual Lift Assembly 18 1 Lower Right Handlebar Arm
8 1 Upper Left Handlebar Arm 19 1 MP3 Cord
9 1 Lower Left Handlebar Arm 20 1 Upper Right Handlebar Arm
10 1 Rail Assembly 21 1 AC Adapter
11 1 Left Pedal 22 1 Silicone Lubricant, Bottle (not shown)
PARTS
3
1
4
5 6
7
2
8
9
10
12
13
14
11
15
16
21
17
20
18
19
