42
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and the
machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a secure location.
Note: Your machine may not match the image. For reference only.
1. Remove screws that attach Console to the Mast. Carefully lift the
Console off the Mast.
2. Disconnect the cables from the back of the Console. Set the Console
and screws safely aside for reassembly.
3. Using a 6 mm hex key, remove the 3 indicated bolts and remove the
Static Handlebar. Set the hardware and Static Handlebar safely aside for
reassembly.
NOTICE: Do not crimp the Heart Rate Cable when removing the Static
Handlebar.
Water bottle holder not shown for clarity
X3
6mm
To Next Page
