Nautilus E616 Service Manual

78
6. Using a #2 Phillips screwdriver, remove the top screw (C1) to free
the Lift Motor ground wire (E). Hand tighten the top screw to hold the MCB
assembly (C) in position on the Frame until reassembly.
7. 'LVFRQQHFWWKH/LIW0RWRUFDEOH(IURPWKH0RWRU&RQWURO%RDUG
after noting the connector locations.
Note: Be sure to note where all cables attach for re-assembly.
D - Power inlet
(line)
D - Power inlet (neutral)
E - Lift motor common
(neutral)
E - Lift motor CW
(line)
E - Lift motor CCW
(line)
E - Lift motor position
potentiometer
F - Lift motor wire
(to Console)
G - Servo control
C1
E - Lift
motor
ground
C
E
The MCB shown is on a Schwinn
™
470 machine.
The MCB shown is on an E626 machine.

Nautilus E616 Specifications

General

Type	Upright
Programs	29
Bluetooth Connectivity	Yes
User Profiles	4
Drive System	Belt
Display	LCD
Heart Rate Monitoring	Contact and Telemetry Enabled
Max User Weight	300 lbs
Warranty	10 years frame, 1 year labor
Flywheel	Perimeter Weighted
Product Weight	78.5 lbs (35.6 kg)
