Nautilus T624 Service Manual

11
3. Unfold the Walking Deck
Slightly push the Walking Deck forward toward the front of the machine. With
your left foot lightly push the top part of the hydraulic lift forward until the
locking tube releases and you can pull the walking deck slightly toward the
rear of the machine. Hold up the rear of the walking deck, and move to the
side of the machine.
Keep clear of the movement path of the walking deck.
The hydraulic lift is set up to drop lightly. Hold onto the walking deck until
approximately 2/3 of the movement down. Make sure that you use proper
lifting technique; bend your knees and keep your back straight. The walking
deck can possibly drop quickly in the last part of the movement.
4. Fully insert the Tilt Restraining Pin into the “Locked” position on the
Walking Deck.
5. With the Tilt Restraining Pin secure, the Treadmill can now be tilted.
A second person is required to assist with the tilting of the machine.
Use proper safety precautions and lifting techniques. Bend your knees
and elbows, keep your back straight and pull up equally with both arms.
Make sure that your own physical strength is capable of tilting the
machine until it rests on the side.
Be aware that as the machine is tilted, the Walking Deck will abruptly
move until the Tilt Restraining Device restricts the movement. Keep
clear of the movement path of the Walking Deck. Injury to you or
damage to the machine can occur.
Do not use the Console to tilt the treadmill. Damage to the treadmill can
occur.

Nautilus T624 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Bluetooth	No
Incline range	0 - 12 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	22
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 55 mm
Running belt thickness	1.5 mm
Running deck thickness	19 mm
