144
Note: The Nautilus™ T626 is used in the following images. The procedure
is the same for the Nautilus™ T624/T684/T686 and Schwinn
®
530/570
models.
1.Unplugthepowercordfromthemachineandwait5minutes.Placethe
power cord in a secure location.
2. Make sure that there is safe clearance around, on and above the
treadmill. Make sure there is no object to spill or cause blockage from the
fully folded position.
Be sure there is adequate height clearance for the raised deck.
3. Using the support bar found below the rear of the walking belt, lift the
walking deck fully upward and engage the hydraulic lift. Be sure that the
hydraulic lift is correctly locked in place. You will hear an audible click
when the hydraulic lift shifts into the locked position.
Use proper safety precautions and lifting techniques. Bend your
knees and elbows, keep your back straight and pull up equally with
both arms. Make sure that your own physical strength is capable of
lifting the walking deck until it engages the locking mechanism. Use
a second person if necessary.
Do not use the walking belt or rear roller to lift the treadmill. These
parts do not lock in place and can abruptly move. Injury to you or
damage to the machine can occur.
4. Make sure that the locking mechanism is engaged. Carefully pull back
on the walking deck and make sure that it does not move. When you
do this, keep clear of movement path in case the treadmill lock is not
engaged.
Do not lean against the treadmill when it is folded. Do not put items
on it that could cause it to become unstable or fall.
!
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet
andthemachineandwait5minutesbeforecleaning,maintainingorrepairingthemachine.Placethepowercordinasecure
location.
Deck Wheel and Shroud
Deck Wheel
and Shroud
