22
U
V
W
AA
DD
CC
CC
EE
FF
CC
Z
Y
GG
DD
GG
BB
BB
BB
Z
X
EE
HH
HH
II
Back
Maintenance Parts ( Frame )
Front
U Power Switch Z Base Support EE Incline Adjuster
V Fuse AA Deck Cushioners FF Pivot Assembly
W Power Input BB Transport Wheel GG Belt Tensioner
X Motor Cover CC Leveler HH Rear Roller Cover
Y Side Foot Support Rails DD Lifting Cylinder II Tilt Restraining Device (T626
only)
