Nautilus T624 Service Manual

27
Condition/Problem Things to Check Solution
Unit operates but incline
does not adjust
MCB Connections Unplug unit from electrical outlet for 5 minutes. Inspect Incline
Motor Assembly cables and be sure they are properly connected
to MCB and not cut or crimped. If any are cut or crimped, re-
place Incline Motor Assembly.
Lower, Middle and Upper
I/O Cables
All wires in the cables should be intact. If any are cut or crimped,
replace cable.
Incline Adjuster Arm Be sure Incline Adjuster Arm is attached to Frame
Console Calibrate MCB (see Engineering Mode -MCB Calibration Proce-
dure)
If the above steps do not resolve the problem, replace Incline
Motor Assembly

Nautilus T624 Specifications

General

Quantity per pack	1 pc(s)
Foldable	Yes
Bluetooth	No
Incline range	0 - 12 %
Maximum speed	19.3 km/h
Minimum speed	0 km/h
Product color	Black, Grey
Number of programs	22
Maximum user weight	136 kg
Backlight color	Blue

Weight and Dimensions

Width	- mm
Weight	- g
Running area (W x L)	20 x 55 mm
Running belt thickness	1.5 mm
Running deck thickness	19 mm
