Nautilus U628 User Manual

7
PARTS
Item Qty Description Item Qty Description
1 1 Main Frame 10 1 Adjustment Knob
2 1 Front Stabilizer 11 1 Seat
3 1 Rear Stabilizer 12 1 Left Pedal (L)
4 1 Mast Boot 13 1 Right Pedal (R)
5 1 Console Mast (with Handlebar Mount) 14 1 Water Bottle Holder
 1 Handlebar Mount Cover 15 1 Power Cord
7 1 Handlebars 1 1 Console Pivot Shroud
8 1 Console 17 1 MP3 Cord
9 1 Seat Post 18 1 Heart Rate (HR) Chest Strap
15
16
10
12 (L)
13 (R)
11
7
1
2
4
8
6
5
14
3
9
17
18
