Nautilus U628 - Assembly Hardware & Tools; Included Hardware Components; Required Assembly Tools

8
HARDWARE / TOOLS
Tools
Included
 mm
Item Qty Description
A 4 Button Head He[ Screw M8 [ 1
B 5 Lock Washer M8
C 4 Flat Washer M8
D 1 T-handle
E 1 Flat Washer, Narrow M8
Note: Select pieces of Hardware have been provided as spares on the Hardware Card.
Be aware that there may be remaining Hardware after the proper assembly of
your machine.
D E
