31
OLD STYLE CONSISTS
SETUP AN OLD STYLE CONSIST
CONSIST 2:00PMCONSIST 2:00PM
CONSIST 2:00PMCONSIST 2:00PM
CONSIST 2:00PM
ENTER=ADV 1=OLDENTER=ADV 1=OLD
ENTER=ADV 1=OLDENTER=ADV 1=OLD
ENTER=ADV 1=OLD
Press SETUP. This screen allows you to choose the type of consist to be created.
For those consists that will contain any basic decoders, press 1. Please note that the
limit on an old style consist is two locomotives or advanced consists. NOTE: Once
you setup an old style consist you will not be able to select a new locomotive to run
unless you store the consist away by pressing recall (or clear the consist). Each cab
may have up to 2 old style consists in recall.
INITIAL SCREEN DISPLAY
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PM
CON: 000 000CON: 000 000
CON: 000 000CON: 000 000
CON: 000 000
This screen is “informational” to show all 4 “slots” for loco’s in the Old Style consist.
Press the ENTER key to continue.
ENTERING THE LEAD LOCO NUMBER
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PM
LEADLEAD
LEADLEAD
LEAD
LOCO: _ LOCO: _
LOCO: _ LOCO: _
LOCO: _
Enter the loco number followed by the ENTER key. The first loco to be added will be
the lead loco (the lead loco number will be displayed on the screen during normal
operation). The consist will respond to this number.
ENTERING THE LOCO DIRECTION
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PM
DIR THIS LOCO: FDIR THIS LOCO: F
DIR THIS LOCO: FDIR THIS LOCO: F
DIR THIS LOCO: F
The locomotive direction is assumed to be forward, if it is to operate in reverse press
the DIRECTION key. This informs the command station the loco is in the line-up
facing reverse. This affects only the direction of the loco, not lighting. Press the
ENTER key to continue.
ADD REAR LOCO
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PMOLD TYPE 2:00PM
OLD TYPE 2:00PM
REAR LOCO: _REAR LOCO: _
REAR LOCO: _REAR LOCO: _
REAR LOCO: _
Enter the second loco address followed by the ENTER key.
