NCE Power Cab - SETUP NCE LIGHTING EFFECTS (Option 6)

44
On NCE decoders CV33 and CV34 do not provide directionality (see SETUP NCE
LIGHTING EFFECTS below) but otherwise operate the same as above. With NCE
decoders direction of operation for function outputs is provided by the lighting effects
CVs 120 through 127.
Lenz and TCS decoders do not follow NMRA standard function mapping procedures.
When you select function mapping you are prompted for the function number to map.
PRESS FUNCTIONPRESS FUNCTION
PRESS FUNCTIONPRESS FUNCTION
PRESS FUNCTION
NUMBER TO MAPNUMBER TO MAP
NUMBER TO MAPNUMBER TO MAP
NUMBER TO MAP
The top line of the LCD displays the function number and the output numbers that
can be controlled by the function.
F2 12345678F2 12345678
F2 12345678F2 12345678
F2 12345678
OUTPUTS: —4——OUTPUTS: —4——
OUTPUTS: —4——OUTPUTS: —4——
OUTPUTS: —4——
Pressing a digit key will enable the output on the decoder when the function is
activated. Pressing the same digit key again will disable the output. In the display
above the 4 key has been pressed so that output number 4 will activate when ever
the F2 button is pressed on your handheld cab. If you were to press another digit
such a 6, both output 4 and output 6 will be controlled by pressing F2.
When mapping functions higher than 3, the top line of the LCD will use small numbers
to indicate the output numbers 10 through 14. To enable/disable these high numbers
press the digit key that is 10 less than the output number. Example: press 0 for
output 10, 1 for output 11, etc. Pressing PROG/ESC will exit from mapping at any
time.
SETUP NCE LIGHTING EFFECTS (Option 6)
You can use this option to customize the lighting effects for your NCE decoder
equipped locomotives. This programming option will only work with NCE decoders.
NCE EFX 07:04NCE EFX 07:04
NCE EFX 07:04NCE EFX 07:04
NCE EFX 07:04
OUTPUT NUMBER:_OUTPUT NUMBER:_
OUTPUT NUMBER:_OUTPUT NUMBER:_
OUTPUT NUMBER:_
Function outputs are numbered from 1 to 14. Do not confuse Output numbers with
Function numbers. The headlight is always output 1 and the reverse light is usually
output 2. You are prompted for the output number to setup. Press the output number
followed by ENTER.
OUTPUT NUMBER:03OUTPUT NUMBER:03
OUTPUT NUMBER:03OUTPUT NUMBER:03
OUTPUT NUMBER:03
USE THUMBWHEEL USE THUMBWHEEL
USE THUMBWHEEL USE THUMBWHEEL
USE THUMBWHEEL
Use the thumbwheel or up/down speed buttons to scroll through the different lighting
effect options. Press ENTER when you get the one you want.
DIR OF OPERATIONDIR OF OPERATION
DIR OF OPERATIONDIR OF OPERATION
DIR OF OPERATION
1=FW 2=RV 3=BOTH1=FW 2=RV 3=BOTH
1=FW 2=RV 3=BOTH1=FW 2=RV 3=BOTH
1=FW 2=RV 3=BOTH
Next press 1,2 or 3 to select the ‘directionality’ of the output. If you want the output
active only in the forward direction of travel - press 1. Press 2 for the effect to
operate only when travelling in reverse. 3 activates the output no matter which
direction the locomotive is travelling.
