NCE Power Cab - Analog Mode; Direction Bit; Enable Long or Short Address; Speed Steps

51
SET CFG?SET CFG?
SET CFG?SET CFG?
SET CFG?
ENTER=NO 1=YESENTER=NO 1=YES
ENTER=NO 1=YESENTER=NO 1=YES
ENTER=NO 1=YES
You will be asked a series of questions regarding the basic operation of the
locomotive. If you are in doubt about the proper answer just press ENTER and you
will usually be OK.
DIRECTION BIT - NORMAL OR REVERSE
Press ENTER for the locomotive to operate in the normal direction or press 1 to
switch the direction of operation.
DIR BIT? 02:00PMDIR BIT? 02:00PM
DIR BIT? 02:00PMDIR BIT? 02:00PM
DIR BIT? 02:00PM
ENTER=NORM 1=REVENTER=NORM 1=REV
ENTER=NORM 1=REVENTER=NORM 1=REV
ENTER=NORM 1=REV
SPEED STEPS - 28 OR 14
If the decoder in this locomotive is an early 14 step decoder then press 1. (all
decoders made since 1997 support 28 speeds). NOTE: If you are wondering how to
set the decoder for 128 speed operation, you do not have to program anything. 128
speed mode is always enabled in decoders that support 128 speed step operation.
SPEED 02:00PMSPEED 02:00PM
SPEED 02:00PMSPEED 02:00PM
SPEED 02:00PM
ENTER=28 1=14 _ENTER=28 1=14 _
ENTER=28 1=14 _ENTER=28 1=14 _
ENTER=28 1=14 _
DC (Analog) MODE
Press ENTER to turn DC operation mode off, press 1 to turn DC mode on. We
recommend leaving DC mode off for most layouts.
DC MODE 02:00PMDC MODE 02:00PM
DC MODE 02:00PMDC MODE 02:00PM
DC MODE 02:00PM
ENTER=NO 1=YES _ENTER=NO 1=YES _
ENTER=NO 1=YES _ENTER=NO 1=YES _
ENTER=NO 1=YES _
This is to prevent all your locomotives from taking off at once in case of a failure in
your power booster or someone accidentally connecting the track to a DC power
supply (it happens more often than you might think).
ADVANCED ACKNOWLEDGE
Press ENTER to turn Advanced Acknowledge mode off, press 1 to turn Advanced
Acknowledge mode on.
ADV ACK? 02:00PMADV ACK? 02:00PM
ADV ACK? 02:00PMADV ACK? 02:00PM
ADV ACK? 02:00PM
ENTER=NO 1=YES _ENTER=NO 1=YES _
ENTER=NO 1=YES _ENTER=NO 1=YES _
ENTER=NO 1=YES _
NOTE: advanced acknowledgment is not operational in any decoders at this time as
the NMRA has not defined how it is to work.
SPEED TABLE SELECTION
If the Standard Speed Table is to be used, press ENTER. If an Alternate (uploadable)
Speed Table in the decoder is to be used, press 1.
SPEEDTBL 02:00PMSPEEDTBL 02:00PM
SPEEDTBL 02:00PMSPEEDTBL 02:00PM
SPEEDTBL 02:00PM
ENTER=STD 1=ALT_ENTER=STD 1=ALT_
ENTER=STD 1=ALT_ENTER=STD 1=ALT_
ENTER=STD 1=ALT_
ENABLE LONG OR SHORT ADDRESS
The short address is used when operating on DCC systems that do not use long
address.
