PROGRAMMING ON THE MAIN
Programming on the Main is also called Operations (OPS) Mode programming. OPS
programming allows you to change parameters while the loco is on the main track
(even while it’s running). This does not affect other locomotives on the track. You
can even change the locomotive address.
OPS PROG 02:00PMOPS PROG 02:00PM
OPS PROG 02:00PMOPS PROG 02:00PM
OPS PROG 02:00PM
PROG LOCO: 003PROG LOCO: 003
PROG LOCO: 003PROG LOCO: 003
PROG LOCO: 003
We first begin by telling the system which locomotive to program. If you want to
program the locomotive you are currently operating just press ENTER. If you wish to
program a different locomotive just enter its address at the above prompt.
WHAT TO PROGRAM
After determining which locomotive you wish to program you will see the following
display. The Power CabTM system provides 9 different OPs mode programming
options.
LOC:1022 02:00PMLOC:1022 02:00PM
LOC:1022 02:00PMLOC:1022 02:00PM
LOC:1022 02:00PM
1=ADR 2=CV 3=CFG1=ADR 2=CV 3=CFG
1=ADR 2=CV 3=CFG1=ADR 2=CV 3=CFG
1=ADR 2=CV 3=CFG
The first three options are displayed. Press ENTER to see more options. For
example: If you wish to set the locomotive address press 1, if you want to program
CVs press 2.
Descriptions of each programming option are described below.
1............................. SET UP LOCOMOTIVE ADDRESS
2............................. CHANGE ANY CV IN THE DECODER
3............................. SET UP THE DECODER CONFIGURATION (CV29)
4............................. MOTOR CONTROL
5............................. FUNCTION MAP
6............................. NCE EFFECTS
7............................. Not Used
8............................. QSI SOUND
9............................. BIN
ADDRESS PROGRAMMING (Option 1)
This option provides a means by which to program the address of your locomotive.
Most decoders allow programming of the locomotive address while on the mainline.
The first thing to do is decide if you want to program a long or short address into the
locomotive.
SET ADDR 03:38PMSET ADDR 03:38PM
SET ADDR 03:38PMSET ADDR 03:38PM
SET ADDR 03:38PM
1=LONG 2=SHORT1=LONG 2=SHORT
1=LONG 2=SHORT1=LONG 2=SHORT
1=LONG 2=SHORT
In DCC there are 2 kinds of addresses (loco numbers), long and short. Short
addresses range from 1 to 127 and long addresses range from 0-9999. We normally
recommend using long addresses for all your locomotives. Consists require the use
of a short address so it is better to conserve short addresses by using long
addresses for individual locomotives. Push the digit button that corresponds to the
type of address you wish to program. You will then be presented with the display
below.
SET ADDR 03:38PMSET ADDR 03:38PM
SET ADDR 03:38PMSET ADDR 03:38PM
SET ADDR 03:38PM
LONG ADDR: _LONG ADDR: _
LONG ADDR: _LONG ADDR: _
LONG ADDR: _
