19
Specifications
1
Notes:
1. Specifications are subject to change without notice. Contact factory for recent specifications.
2. Brightness shown is without a Touch Screen or A/R filter installed.
3. Applies to RGBS and Sync On Green (SOG).
9
Model SC-WU42 SC-WU55
Viewable Diagonal (inches)
42.0 54.6
Brightness
2
(cd/m², typical)
550 500
Native Resolution
1920 x 1080 1920 x 1080
Dot Pitch (mm)
.485 .63
Vertical Viewing Angle (degrees)
178 176
Horizontal Viewing Angle (degrees)
178 176
Contrast Ratio (nominal)
700:1 550:1
Vertical Freq (Hz, max)
85 85
Bandwidth (MHz, max)
135 135
VGA Input signal level at 75 Ohm
0.7 V p-p 0.7 V p-p
Pixel Clock (MHz, max)
170 170
HD-SDI / SDI Input signal level
.8 to 2.0 V p-p .8 to 2.0 V p-p
S-Video Input signal level
0.7 V p-p 0.7 V p-p
Composite Input signal level
1 V p-p 1 V p-p
Sync On Green (SOG)
0.7 V p-p 0.7 V p-p
RGBS Input signal level
0.7 V p-p 0.7 V p-p
Sync
0.4 to 4.0 V p-p 0.4 to 4.0 V p-p
Pixel Clock (MHz, max)
3
140 140
Power Consumption (nominal)
200w 360w
Display Weight (lbs, (kg))
63 (28.6) 112 (51)
Environmental
Operating Temperature
0 to 40
0
C 0 to 40
0
C
Storage Temperature
-20 to 50
0
C -20 to 50
0
C
Relative Humidity (non condensing)
10-90% 10-90%
