20
Video Formats
Horiz.
Freq
(kHz)
Interlaced /
Progressive
Aspect Standard
Digital/Analog
Serial Digital and Analog
576/50i (PAL) SDI Comp, S-video, RGBS, YPbPr 15.625 Interlaced 16:9 / 4:3 SMPTE 259M/C ITU 601
480/60i (NTSC) SDI Comp, S-video, RGBS, YPbPr 15.734 Interlaced 16:9 / 4:3 SMPTE 259M/C ITU 601
576/50p RGBS, YPbPr, SOG 31.250 Progressive 16:9 / 4:3 --
480/60p RGBS, YPbPr, SOG 31.469 Progressive 16:9 / 4:3 -SMPTE 293M
720/50p RGBS, YPbPr, HD-SDI 37.500 Progressive 16:9 -SMPTE 296M
720/60p RGBS, YPbPr, HD-SDI 45.000 Progressive 16:9 -SMPTE 296M
1080/60i RGBS, YPbPr, HD-SDI 33.750 Interlaced 16:9 -SMPTE 274M
Up to 1024/60p SOG 64.0, max Progressive
Video Inputs Connector Type
HD-SDI / SDI BNC, 75 Ohm terminated
S-video BNC x 2 (Y & C), 75 Ohm terminated
S-video DIN-4
RGBS / YPbPr BNC x 5, 75 Ohm terminated
RGBS / YPbPr HD-15
Composite BNC, 75 Ohm terminated
Sync-On-Green (SOG) BNC, 75 Ohm terminated
Graphics Inputs
DVI DVI-d
VGA HD-15
Outputs
HD-SDI / SDI BNC
S-Video DIN-4
RGBS / YPbPr BNC x 5
RGBS / YPbPr HD-15
Composite / SOG BNC
Proprietary Notice and Liability Disclaimer:
The information disclosed in this document, including all designs and related materials, is the valuable property of
NDS and / or its licensors and, as appropriate, they reserve all patent, copyright, and other proprietary rights to
this document, including all design, manufacturing reproduction, use, and sales rights thereto, except to the extent
said rights are expressly granted to others.
Cleaning Instructions:
Follow your hospital protocol for the handling of blood and body fluids. Clean the display with a
diluted mixture of mild detergent and water. Use a soft towel or swab. Use of certain cleaning agents
may cause degradation to the labels and plastic components of the product. Consult cleanser
manufacturer to see if agent is compatible with it. Do not allow liquid to enter the display.
All product names and trademarks or registered trademarks are the property of their respective holders.
