This manual is designed to assist the user with proper installation, setup and operation of the Radiance Medical
LCD display. Depending on the model and options that were purchased, some of the features and options in this
manual may not apply to the display you are using.
A black tab number on the side of the page denotes the beginning of a section.
The functional descriptions in this manual are representative of:
Model Number: SC-WU42
Firmware BIOS: 58H0007 Version A and later.
Model Number: SC-WU55
Firmware BIOS: 58H0010 Version A and later.
Due to the technology utilized to manufacture flat-panel screens, characters will appear crisper with sharper edges
than that of a computer CRT. For the same reason, live video may appear a little blocky. Users not familiar with
the image differences should familiarize themselves before utilization in a critical application and determine its
usability.
For mission critical applications, we strongly recommend that a replacement unit be immediately available.
Powering On The Unit:
Connect the power supply to the display via the power plug. Plug in the AC adapter. Connect the video source to
the Radiance display. Apply power to the peripheral device, then to the display. The NDS logo is displayed,
followed shortly by video.
The electronics, designed by NDS, incorporates proprietary SmartSync™ technology which at initialization,
examines the incoming signal and automatically displays the video image in its proper format. This eliminates
making adjustments to most video sources. To fine tune the image, please refer to “Image Adjustments” on page
4.
First time users and initial test:
Visually, Flat-Panel (LCD) images will look crisper than those of a traditional CRT. It is recommended that first
time users view the display next to a CRT to familiarize themselves with any subtle differences in viewing quality.
2
1
About This Manual
Quick Startup
