NEC DS2000 Hardware Manual

Wall-Mount Kit
DS2000 Hardware Manual Section 4: Optional Equipment ◆ 4-11
4
To mount the telephone on a wall plate (Figure 4-11):
1. Snap the wall-mount bracket onto the wall plate.
2. Plug the telephone’s line cord into the jack in the wall plate and into the telephone.
3. Place the telephone on top of the wall-mount bracket and snap into place.
To remove the telephone from the wall mount bracket (Figure 4-12):
1. From the front of the phone, grab the tabs that secure the telephone to the wall-mount bracket.
2. While pressing in the tabs, lift up the phone until it snaps clear of the wall-mount bracket.
Figure 4-11: Mounting on a Wall Plate
Figure 4-12: Removing the Wall-Mount Bracket
80000 - 43A
Tab on phone must snap
into cutout on wall mount bracket
80000 - 45
Press down tabs
on phone and
pull bracket in
direction of arrows
