Direct Wall Mounting
If a standard wall plate is not available, mount the telephone
directly on the wall. Before mounting the telephone, consider
the following:
Select a location away from electrical cables, pipes, or
other items behind the mounting location that could
cause a hazard when inserting screws into the wall.
Make sure the wall material is capable of supporting
the weight of the base unit.
Use #10 screws with anchoring devices suitable for the
wall material where the base unit will be placed.
To mount the telephone:
1. Insert two mounting screws 3-15/16 inches apart.
Allow about 3/16 of a inch between the wall and screw
heads for mounting the telephone.
Figure 3-9 Inserting Screws into the Wall for Wall
Mounting the Telephone
