NEC iS8-2K - Page 53

Appendix
37
40 IB UART1 Fail
41 IB IIC Fail
42 IB Ethernet Fail
43 IB Sync-Serial Fail
44 IB File System Fail
45 IB Formatter Fail
46 IB Flash Protect Fail
47 IB GPI Macro Fail
48 IB A/D Macro Fail
60 PB Diag Not Performed
61 PB FPGA Code Invalid
62 PB FPGA INITZ Fail
63 PB McBSP XRDY Fail
64 PB FPGA Done Fail
65 PB FPGA Reg R/W Fail
66 PB Serial-ID Chip Fail
67 PB CLUT-SRAM Fail
68 PB OvFS-SDRAM Fail
69 PB Resizer FIR Fail
70 PB Resizer FIFO Fail
71 PB Other Fail
