Connections - continued
RGB/HV OUT
RGB/HV IN
VGA (D-SUB)
DVI (DVI-D)
LCD Monitor
RCA
External
Speakers
VC
R or Laser disc player
Connecting to a Stereo Amplier
You can connect your stereo amplier to your LCD monitor. Refer to your amplier owner’s
manual for more information.
Connect the LCD Monitor to a Stereo Amplier
Turn on the LCD monitor and the amplier only aer all connections have been made.
Use an RCA cable to connect the AUDIO OUT connector (RCA) on the LCD monitor and
the audio input on the amplier.
Do not reverse the audio le and right jacks.
e AUDIO IN is used for audio input.
e AUDIO OUT jack outputs sound from the selected Audio input.
To Audio Right
Amplifier
To Audio Left
To Audio Right
To Audio Left
Denotes AV unit function. All AV functions are enabled with the AV
unit is installed. Not all models have the AV unit installed.
Denotes Digital Tuner function. All DTV and AV functions are
enabled when the DTV unit is installed. Not all models will have
the digital tuner installed.
1-24
