NEC MULTEOS M40 User Manual

English
English-43
Specications M40
LCD Module (40" / 102.0 cm diagonal)
Pixel Pitch 0.461 mm
Resolution 1920 x 1080 pixels
Color Over 16 million colors (depending on video card used)
Brightness 450cd/m² (typ)
Contrast Ratio 1000:1 (typ)
Viewing Angle Up 89 / Down 89 / Left 89 / Right 89 (typ) @ CR >10
Frequency Horizontal ANALOG: 15.625/15.734kHz, 31.5kHz - 91.1kHz
DIGITAL: 31.5kHz - 91.1kHz
Vertical 50Hz to 85Hz
Pixel Clock 25.2MHz - 162.0MHz
Viewable Size 885.6 x 498.2mm
Input Signal
DVI DVI-D 24 PIN DIGITAL RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080 (60Hz)
VGA 15 Pin Mini D-sub
Analog RGB
0.7V p-p, Input Impedance 75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080 (60Hz)
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video:
0.3Vp-p Neg.
RGB/HV BNC (R,G,B,H,V)
Analog RGB
0.7V p-p, Input Impedance 75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*, 1920X1080(60Hz)
Sync
Separate: TTL level (Pos./Neg.)
Composite sync on Green Video:
0.3Vp-p Neg.
HDMI HDMI Type-A Digital RGB
HDMI
1080p,1080i,720p 50Hz/60Hz, 576p, 480p
DVD/HD
RCA (Y, Cb/Pb,
Cr/Pr)
Component
Y : 1.0Vp-p/75ohm, Cb/Cr (Pb/Pr) : 0.7Vp-p/75 ohm
HDTV/DVD:1080p,1080i,720p 50Hz/60Hz, 576p , 480p , 576i, 480i
VIDEO
BNC
Composite
1.0V p-p Input Impedance 75 ohm
RCA NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO DIN 4 pin S-VIDEO
Y: 1.0Vp-p/75ohm C: 0.286Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
TV
75 ohm
F-terminal
Analog
Terrestrial broadcast
NTSC: VHF(2-13ch),UHF(14-69ch)
Analog Cable CATV 1-130ch
Digital
Terrestrial broadcast
ATSC (8VSB):2-69ch
Digital Cable 64/256 QAM : 1-135ch
Output Signal RGB/HV BNC (R,G,B,H,V) Analog RGB Analog RGB Video:
0.7V p-p with 75 ohm terminated
Separate HV sync: TTL level (Pos./Neg.) with 2.2k ohm terminated
VIDEO BNC COMPOSITE Output, Composite 1.0V p-p with 75 ohm terminated
Audio AUDIO Input RCA (L/R) x 2 Analog Audio Stereo L/R 0.5Vrms/more than 22K ohm
STEREO
Mini Jack
HDMI Type-A DIGITAL Audio PCM 32, 44.1, 48KHz (16bit)
AUDIO Output STEREO
Mini Jack
Analog Audio RCA PIN-JACK L/R: 1 Output, 0.5Vrms with 1k ohm terminated
Optical S/PDIF
connector
Digital Audio S/PDIF Optical Digital audio output (PCM/Dolby Digital)**
Speaker Output External Speaker Jack 15W + 15W (8 ohm)
Control RS-232C: IN 9 Pin Mini D-sub
RS-232C: OUT 9 Pin Mini D-sub (daisy chain)
Power Supply 3.0-1.2A@100-240V AC, 50/60Hz
Operational
Environment
Temperature 5˚C to 40˚C/41˚F to 104˚F
Humidity 10% to 80%
Storage
Environment
Temperature -20˚C to 60˚C/-4˚F to 140˚F
Humidity 10% to 90% (without condensation) / below 60% over 40˚C
Dimensions Net 981.8 (W) x 627.9 (H) x 400 (D) mm (with Stand)
981.8 (W) x 582.4 (H) x 142.5 (D) mm (without Stand)
627.4 (W) x 981.8 (H) x 142.5 (D) mm (Portrait mode without Stand)
Gross 1147.0 (W) x 780.0 (H) x 540.0 (D) mm
Weight Net 32.6kg / 71.9 lbs.
Gross 41.9kg / 92.4 lbs.
VESA compatible arm
mounting interface
3 x 200mm x 200mm (8 Holes)
2 x 200mm x 200mm (6 Holes)
Complied Regulatory
and Guidelines
UL 60950-1/CSA C22.2 No.60950-1/ TUV-GS/EN60950-1
FCC-B/DOC-B/EN55022-A/EN55024/EN61000-3-2/EN61000-3-3/CE
Power Management VESA DPM
Plug & Play VESA DDC2B
DDC/CI
Accessories User’s manual, Power Cord, Video Signal Cable, Remote Control, AA Battery x 2, Clamp x 3, Screw x 5, CD-ROM, Main switch cover x 1
*Compressed Image
**Audio Output for Digital Terrestrial broadcast
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
