English-28
OSM Controls - continued
CLOCK PHASE
VGA, RGB/HV, DVD/HD
input only
Adjusts the visual “noise” on the image.
H RESOLUTION
DVI, VGA, RGB/HV
input only
Adjusts the horizontal size of the image.
V RESOLUTION
DVI, VGA, RGB/HV
input only
Adjusts the vertical size of the image.
ZOOM MODE Select the aspect ratio of the screen image.
BASE ZOOM
Choose the zoom method
16:9
14:9
DYNAMIC
OFF
CUSTOM
Same aspect ratio as the LCD panel.
14:9
Expands a 4:3 picture to fill the screen in a non-linear (non-proportionate) manner and
some of the image will be lost due to expansion. DYNAMIC is the same as FULL size
image when HDTV 1080i signal is input.
Selecting “OFF” will display the image in a 1 by 1 pixel format. (If the input resolution is
higher than a 1920 x 1080 resolution, the image will be scaled down to fit the screen.
Displays an image as large as possible without changing the aspect ratio or cutting off
part of the image.
ZOOM
H ZOOM
V ZOOM
H POS
V POS
Maintains the aspect ratio while zooming.
Amount of horizontal zoom. Can be adjusted for each BASE ZOOM setting.
Amount of vertical zoom. Can be adjusted for each BASE ZOOM setting.
Horizontal position. Can be adjusted for each BASE ZOOM setting.
Vertical position. Can be adjusted for each BASE ZOOM setting.
INPUT RESOLUTION
VGA and RGB/HV input only
If there is a problem with signal detection, this function forces the monitor to display the
signal at the desired resolution.
If no problem is detected, the only available option will be “AUTO”.
AUTO
1024x768
1280x768
1360x768
1366x768
1440x1050
1680x1050
ADJUST RESET Resets the following settings within the ADJUST menu back to factory setting:
AUTO ADJUST, H POSITION, V POSITION, CLOCK, CLOCK PHASE, H RESOLUTION, V
RESOLUTION, ZOOM MODE, INPUT RESOLUTION.
AUDIO
BALANCE
TREBLE
BASS
PIP AUDIO Selects source of PIP audio.
AUDIO RESET Resets “AUDIO” options back to factory settings.
SCHEDULE OFF TIMER Sets the monitor to power off after a length of time between 1 and 24 hours.
SCHEDULE SETTING Creates a working schedule for the monitor to use. See page 34 for instructions.
SCHEDULE LIST List of schedules.
DATE & TIME Sets the date, time, and daylight saving region. Date & time must be set in order for the
“SCHEDULE” function to operate.
To Next Page
