English-8

2) Stand Removal

To detach stand, place the monitor face down as shown

in Figure 2. Remove the screws from the back of the

stand as indicated in Figure 3. Remove the 2 additional

screws located on the bottom of the stand (Figure 3).

Li up stand to remove. Aer stand is removed, replace

the screws into the original holes.

NOTE: e number of screws will vary depending on

the model (Figure 3).

To reattach the stand. Place the monitor face down on

the protective sheet to prevent damage. Remove the

screws from their holes as indicated in Figure 3. Slide

the stand into place, making sure that the inside tabs

located on the le and right of the stand are placed into

the corresponding slots on the display (Figure 4).

e bottom of the stand should t underneath the

monitor. Use the screws to secure the stand to the

monitor

NOTE: When removing stand, be sure to remove the

2 screws on the bottom of the stand (Figure 3). Not

removing these screws will result in damage to the

display.

Installation - continued

Figure 4

2 screws under stand

Circles indicate screw locations (8).

Figure 3

1-9
