NEC MULTEOS M40 User Manual

English
:c\a^h]"'*
Power Indicator
Mode Status Indicator Light
Power ON Green
Power OFF (ECO STANDBY)*
Power consumption under 1W
Red
Power OFF (STANDBY)
Power consumption under 5W
Amber
Power Save Amber Blinking
Power Standby when
“SCHEDULE SETTINGS”
enabled
Green and Amber
blink alternately
Diagnosis (Detecting failure) Red Blinking
(See Trouble Shooting page 41)
*When in Eco Standby Mode RS-232C controls do not function.
Power Management
e LCD monitor follows the VESA approved DPM Power
Management function.
epowermanagementfunctionisanenergysavingfunc-
tion that automatically reduces the power consumption of
thedisplaywhenthekeyboardorthemousehasnotbeen
used for a xed period of time.
e power management feature on your new display has
beensettothe“ON”mode.isallowsyourdisplaytoenter
a Power Saving Mode when no signal is detected. is could
potentially increase the lifetime of the display while power
consumption is decreased.
STANDBY mode is used when the display is connected to an
RS-232C cable or when using the INPUT DETECT function.
ECO STANDBY uses less power, but the RS-232C and
INPUT DETECT functions are not available.
Picture Size
e size of the picture can be changed depending on the
aspect ratio (4:3, 16:9, etc.) of the input signal.
Picture Mode
Choose the Picture Mode that is most suitable for the type of
contentthatisshown.
Standard: for images
sRGB: For text based applications.
Highbright: formovingimages
Cinema: for movies
STANDARD sRGB HIGHBRIGHT
STANDARD CINEMA HIGHBRIGHT
DVI, VGA,
RGB/HV, OPTION
HDMI, DVD/HD,
VIDEO, TV
Information OSM
e Information OSM provides information such as: Moni-
torID,InputSource,PictureSize,etc.PresstheDISPLAY
button on the remote to bring up the Information OSM.
See page 35 for detailed explanation.
#BTJD0QFSBUJPO #Yedj_dk[Z
Monitor ID:1
Target ID:5
DVI
AUDIO: IN1
SIZE:FULL
1024 X 768
48KHz/60Hz
Signal Type
4:3
NORMAL SIZE RECOMMENDED SIZE
NORMAL
ZOOM
(DYNAMIC)
FULL
WIDE
Squeeze
Letterbox
DVI, VGA, RGBH/V, OPTION FULL ZOOM NORMAL
FULL WIDE ZOOM NORMAL
HDMI, DVD/HD, VIDEO, TV
1-26
