Page #31 background imageLoading...
Page #31 background image
English-30
OSM Controls - continued
OSM TRANSPARENCY Set the transparency level of the OSM.
OFF
TYPE1
TYPE2
OSM RESET Resets the following settings within the OSM menu back to factory setting:
OSM TURN OFF, OSM POSITION, INFORMATION OSM, and OSM TRANSPARENCY.
MULTI DISPLAY MONITOR ID Sets the monitor ID number from 1-26.
IR CONTROL Selects the mode of the monitor for use with the infra-red remote control when using
the RS-232C daisy chain.
NORMAL
PRIMARY
SECONDARY
LOCK
The monitor will be controlled normally by wireless remote controller.
Choose “PRIMARY” for the first monitor within an RS232-C daisy chain.
Choose “SECONDARY” for all subsequent monitors within an RS232-C daisy chain.
Prevents the monitor from being controlled by wireless remote controller. To return to
normal operation, press the “DISPLAY” button on the remote controller for 5 seconds.
TILE MATRIX Allows one image to be expanded and displayed over multiple screens (up to 25)
through a distribution amplifier.
H MONITORS
V MONITORS
POSITION
TILE COMP
ENABLE
Number of monitors arranged horizontally.
Number of monitors arranged vertically.
Select which section of the tiled image to be displayed on the monitor.
Turns the TILE COMP feature on.
Enables Tile Matrix.
POWER ON DELAY Adjusts the delay time between being in “standby” mode and entering “power on”
mode.
“POWER ON DELAY” can be set between 0 and 50 seconds.
MULTI DISPLAY RESET Resets the following settings within the MULTI DISPLAY menu back to factory setting:
MONITOR ID, IR CONTROL, TILE MATRIX, POWER ON DELAY.
DISPLAY
PROTECTION
POWER SAVE Sets how long the monitor waits to go into power save mode after a lost signal.
STANDBY MODE Lowers power consumption.
Note: RS232-C Function is lost when in Eco Standby mode.
HEAT STATUS Displays status of the COOLING FAN, BRIGHTNESS and TEMPERATURE.
FAN CONTROL Cooling fan reduces the temperature of the display.
SCREEN SAVER Use the SCREEN SAVER function to reduce the risk of Image Persistence.
GAMMA
BRIGHTNESS
MOTION
The gamma curve becomes narrow, reducing contrast and cutting down the risk of
image retention.
The brightness is decreased when “ON” is selected.
The screen image is slightly expanded and moves in 4 directions (UP, DOWN, RIGHT,
LEFT) at user determined intervals.
SIDE BORDER COLOR Adjusts the color of the side borders when a 4:3 image is displayed.
Press + button, the bar will become lighter.
Press - button, the bar will become darker.
AUTO BRIGHTNESS
DVI, VGA, RGB/HV
input only
Adjusts the brightness level according to the input signal.
CHANGE SECURITY
PASSWORD
Allows the security password to be changed. Factory preset password is 0000.
SECURITY LOCK Locks the security password.
DISPLAY
PROTECTION RESET
Resets the following settings within the Picture menu back to factory setting:
POWER SAVE, STANDBY MODE, FAN CONTROL, SCREEN SAVER, SIDE BORDER
COLOR, AUTO BRIGHTNESS.
1-31
