NEC MultiSync P404 User Manual

English-23
English
Media Player settings
Select the icon in the fi le list screen or top screen of the Media Player to display the confi guration screen of the Media Player.
The following settings can be confi gured on the confi guration screen.
SLIDESHOW
Menu Function
SCREEN SIZE Selects ACTUAL SIZE or BEST FIT.
PLAY MODE Selects AUTO or MANUAL.
INTERVAL Sets interval time.
REPEAT Check the check box to repeat slideshow.
AUDIO FILE Selects an audio fi le.
BGM Check the check box to enable BGM.
PLAY END SCREEN Selects a setting after slideshow is down.
BLACK SCREEN: after slideshow has been done, black is displayed on the screen.
FILE LIST: Gets back to Audio fi le setting.
SAVE LAST SCREEN: The last slideshow image is kept on the screen.
MEDIA PACKAGE
Menu Function
SCREEN SIZE Selects ACTUAL SIZE or BEST FIT.
INTERLOCK POWER Check the check box to enable the monitor to be turned ON or STANDBY by the media package schedule.
PLAY END SCREEN Selects a setting after slideshow is down.
BLACK SCREEN: after slideshow has been done, black is displayed on the screen.
FILE LIST: Gets back to Audio fi le setting.
AUTO PLAY
Automatically displays selected folder when the monitor is turned on the select MP as input.
Menu Function
AUTO PLAY OFF: Automatic play mode is off.
SLIDESHOW: Automatically plays a selected fi le.
FOLDER Select a fi le.
PRESET CONTENTS
Plays selected folder when the monitor has no signal input.
Menu Function
ENABLE Check the check box to enable preset contents.
FOLDER Select a fi le.
Please press OK to activate above settings.
If OK is not pressed, settings that you set are not activated.

NEC MultiSync P404 Specifications

General

Panel life	- h
Panel type	SPVA
Pixel pitch	- mm
Response time	8 ms
Display diagonal	40 \
Display brightness	700 cd/m²
Display technology	LCD
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Supported video modes	720p, 1080p
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	101.6 cm
Active display area (W x H)	885.6 x 498.2 mm
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 2160, 3840 x 2160, 4096 x 2160
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Ethernet LAN data rates	100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Multi-display supported	-
Operating hours (hours/days)	24/7
Power consumption (standby)	3 W
Power consumption (typical)	90 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	13.2 mm
Panel mounting interface	300 x 300 mm
Sustainability certificates	RoHS, ENERGY STAR
Certification	C-tick; CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL/CSA; VCCI
RMS rated power	20 W
Cables included	AC, DVI
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPEG1, MPEG2, MPG, WMV
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	54.7 mm
Width	918 mm
Height	530.6 mm
Weight	14500 g
