Page #45 background imageLoading...
Page #45 background image
English-43
English
SYSTEM
MONITOR INFORMATION Indicates the model and serial number of your monitor and fi rmware version.
CARBON SAVINGS: Display the estimated carbon saving information in kg-CO2. The carbon footprint factor in
the carbon saving calculation is based on the OECD (2008 Edition).
CARBON USAGE: Display the estimated carbon usage information in kg-CO2. This is the arithmetic estimation,
not actual measurement value. This estimation is based without any options.
FIRMWARE Displays fi rmware version that is installed to the monitor.
MAC ADDRESS Displays the MAC ADDRESS.
FACTORY RESET All items are returned to factory shipment state.
NOTE: You can reset all items in all daisy chain displays. Please be careful to avoid resetting all items
inadvertently.
Default values can be provided on request.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NEC MultiSync P404 and is the answer not in the manual?

NEC MultiSync P404 Specifications

General IconGeneral
Panel life- h
Panel typeSPVA
Pixel pitch- mm
Response time8 ms
Display diagonal40 \
Display brightness700 cd/m²
Display technologyLCD
Vertical scan range24 - 85 Hz
Horizontal scan range31.5 - 91.1 kHz
LED backlighting typeEdge-LED
Supported video modes720p, 1080p
Contrast ratio (typical)4000:1
Display number of colors1.073 billion colors
Display diagonal (metric)101.6 cm
Active display area (W x H)885.6 x 498.2 mm
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 2160, 3840 x 2160, 4096 x 2160
USB version2.0
USB ports quantity5
DisplayPorts quantity3
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Ethernet LAN data rates100 Mbit/s
VGA (D-Sub) input ports1
HDMI input ports quantity2
Multi-display supported-
Operating hours (hours/days)24/7
Power consumption (standby)3 W
Power consumption (typical)90 W
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
OrientationHorizontal/Vertical
Product colorBlack
Product designDigital signage flat panel
Bezel width (bottom)13.2 mm
Panel mounting interface300 x 300 mm
Sustainability certificatesRoHS, ENERGY STAR
CertificationC-tick; CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL/CSA; VCCI
RMS rated power20 W
Cables includedAC, DVI
Audio formats supportedMP3, WAV
Image formats supportedJPG, PNG
Video formats supportedFLV, H.264, MOV, MP4, MPEG1, MPEG2, MPG, WMV
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth54.7 mm
Width918 mm
Height530.6 mm
Weight14500 g
