Page #33 background imageLoading...
Page #33 background image
English-31
English
Setting
INPUT
DVI Select input signal.
HDMI1
HDMI2
DisplayPort1
DisplayPort2
VGA (RGB/YPbPr)
VIDEO
MP Displays images or movies stored in microSD memory card or USB storage device. Please refer to the Media
Player setting (See page 20).
OPTION*
3
Select input signal.
PICTURE MODE Selects picture mode for the image that is displaying. See page 29.
NOTE: If WHITE is not set at NATIVE, WHITE is not available when SPECTRAVIEW ENGINE is ON.
If CUSTOM is not set at GAMMA, CUSTOM VALUE is not available when SPECTRAVIEW ENGINE is ON.
Please set CST at GAMMA if you set CUSTOM VALUE.
BRIGHTNESS*
1
BACKLIGHT Adjusts the overall image and background brightness. Press + or - to adjust.
NOTE: When MODE1 or MODE2 is selected in ROOM LIGHT SENSING, this function cannot be changed.
BRIGHTNESS*
2
Adjusts the image brightness in relationship to the background. Press + or - to adjust.
GAMMA*
1,
*
2
Select a display gamma for best picture quality.
NATIVE Gamma correction is handled by the LCD panel.
2.2 Typical display gamma for use with a computer.
2.4 Good for video (DVD, etc.)
S GAMMA Special gamma for certain types of movies. Raises the dark parts and lowers the light parts of the image
(S-Curve).
DICOM SIM. DICOM GSDF curve simulated for LCD type.
PROGRAMMABLE1, 2, 3
A programmable gamma curve can be loaded using NEC optional software.
COLOR*
2
COLOR Adjusts the color depth of the screen. Press + or - to adjust.
COLOR
TEMPERATURE*
1
Adjusts the color temperature of the entire screen. A low color temperature will make the screen reddish. A high
color temperature will make the screen bluish. If TEMPERATURE needs further adjustment, the individual R/G/B/
levels of the white point can be adjusted. To adjust the R/G/B levels, CUSTOM must be showing as the COLOR
TEMP selection.
NOTE: Predefi ned 6500k is set in picture mode and cannot be changed.
When PROGRAMMABLE1, PROGRAMMABLE2 or PROGRAMMABLE3 is selected in GAMMA CORRECTION,
this function cannot be changed.
COLOR CONTROL Adjusts the hue of the Red, Yellow, Green, Cyan, Blue and Magenta.
HUE
MP, VIDEO inputs only
Adjusts the hue of the screen. Press + or - to adjust.
CONTRAST*
1,
*
2
Adjusts the image brightness in relationship to the input signal. Press + or - to adjust.
SHARPNESS*
1
Adjusts the crispness of the image. Press + or - to adjust.
*1: If SPECTRAVIEW ENGINE is ON, this function is grayed out.
*2: This function is not available when sRGB is selected at PICTURE MODE.
*3: When you select OPTION for signal input, this function depends on which option board you use.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NEC MultiSync P404 and is the answer not in the manual?

NEC MultiSync P404 Specifications

General IconGeneral
Panel life- h
Panel typeSPVA
Pixel pitch- mm
Response time8 ms
Display diagonal40 \
Display brightness700 cd/m²
Display technologyLCD
Vertical scan range24 - 85 Hz
Horizontal scan range31.5 - 91.1 kHz
LED backlighting typeEdge-LED
Supported video modes720p, 1080p
Contrast ratio (typical)4000:1
Display number of colors1.073 billion colors
Display diagonal (metric)101.6 cm
Active display area (W x H)885.6 x 498.2 mm
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 2160, 3840 x 2160, 4096 x 2160
USB version2.0
USB ports quantity5
DisplayPorts quantity3
Compatible memory cardsMicroSD (TransFlash), MicroSDHC
Ethernet LAN data rates100 Mbit/s
VGA (D-Sub) input ports1
HDMI input ports quantity2
Multi-display supported-
Operating hours (hours/days)24/7
Power consumption (standby)3 W
Power consumption (typical)90 W
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
OrientationHorizontal/Vertical
Product colorBlack
Product designDigital signage flat panel
Bezel width (bottom)13.2 mm
Panel mounting interface300 x 300 mm
Sustainability certificatesRoHS, ENERGY STAR
CertificationC-tick; CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL/CSA; VCCI
RMS rated power20 W
Cables includedAC, DVI
Audio formats supportedMP3, WAV
Image formats supportedJPG, PNG
Video formats supportedFLV, H.264, MOV, MP4, MPEG1, MPEG2, MPG, WMV
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth54.7 mm
Width918 mm
Height530.6 mm
Weight14500 g
