NEC MultiSync P404 User Manual

English-69
English
Specifi cations - V554
Product Specifi cations
LCD Module
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Viewing Angle:
55"/138.78 cm diagonal
0.630 mm
1920 x 1080
Over 1073 million colors (depending on display card used)
500 cd/m
2
(Max.) @25°C
1200:1
89° (typ) @ CR>10
Frequency Horizontal:
Vertical:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz
50.0 - 85.0 Hz (Analog Input)
24.0 - 85.0 Hz (Digital Input)
Pixel Clock Analog: 13.5 MHz, 25.0 MHz - 195.0 MHz
Digital: 25.0 MHz - 165.0 MHz (DVI), 25.0 MHz - 600.0 MHz (HDMI/DisplayPort)
Viewable Size 1209.6 x 680.4 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, 1920X1080 (60Hz), 1080p, 1080i
DisplayPort DisplayPort Connector Digital RGB DisplayPort Complies with Standard V1.2, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 3840x2160 (24Hz/30Hz/60Hz
(DisplayPort1.2))*
1,
*
4
VGA
(RGB)*
4
15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920X1080 (60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI HDMI Connector Digital YUV
Digital RGB
HDMI
VGA60, SVGA60, XGA60, WXGA60, SXGA60, UXGA60*
1
, WUXGA60*
1
, 1920x1080 (60 Hz),
1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz,
3840x2160 (30Hz/24Hz/25Hz/60Hz (MODE2))*
1,
*
4
, 4096x2160 (24Hz)*
1,
*
4
VGA
(YPbPr)*
4
15pin Mini D-sub Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p, 1080i, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
VIDEO*
4
RCA port Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
DisplayPort DisplayPort Connector Digital RGB DisplayPort Complies with Standard V1.2, applicable to HDCP V1.3
AUDIO
AUDIO
Input
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
DisplayPort Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO
Output
Stereo Mini Jack Analog Audio Stereo L/R 0.5 Vrms
Speaker Output External Speaker Jack 15 W + 15 W (8 ohm)
Internal Speaker 10 W + 10 W (Stereo)
Control RS-232C In:
LAN:
Remote IN:
9 Pin D-sub
RJ-45 10 BASE-T/100 BASE-TX x 2
Stereo Mini Jack 3.5 ɸ
SD card Hub Port: microSD card. Up to 32GB microSDHC is supported.
USB Hub USB1:
USB2:
USB CM1 (2A):
USB CM2:
USB MP:
USB 2.0 Downstream port
USB 2.0 Upstream port
Power supply port, 5V/2A
USB service port for maintenance
Media Player/Firmware update port
Power Supply 3.3 - 1.4 A @ 100-240V AC, 50/60Hz
Power Consumption Normal operation: Approx. 110 W
Operational Environment Temperature*
2
:
Humidity:
Altitude:
0 - 40°C / 32 - 104°F, 0 - 35°C / 32 - 95°F (Slot 2 type PC with Face up position or with Face
down position)
20 - 80% (without condensation)
0 - 3000 m (Brightness may decrease with altitude)
Storage Environment Temperature:
Humidity:
-20 - 60°C / -4 - 140°F
10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension 1244 (W) x 714.8 (H) x 62.9 (D) mm/49 (W) x 28.1 (H) x 2.5 (D) inches (w/o Deco Dimension)
Weight 24.6 kg (54.2 lbs)
VESA compatible mounting interface 300 mm x 300 mm (M6, 4 Holes)
Power Management VESA DPM
Plug & Play VESA DDC2Bi, DDC/CI, DisplayPort
Power supply for Slot 2 type OPTION 16V/3.6 A
NOTE: Technical specifi cations are subject to change without notice. *1: Compressed image.
*2: When you use option board accessories, please contact your supplier for detailed information.
*3: Displayed text may be blurred.
*4: Common terminal.

NEC MultiSync P404 Specifications

General

Panel life	- h
Panel type	SPVA
Pixel pitch	- mm
Response time	8 ms
Display diagonal	40 \
Display brightness	700 cd/m²
Display technology	LCD
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Supported video modes	720p, 1080p
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	101.6 cm
Active display area (W x H)	885.6 x 498.2 mm
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 2160, 3840 x 2160, 4096 x 2160
USB version	2.0
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Ethernet LAN data rates	100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Multi-display supported	-
Operating hours (hours/days)	24/7
Power consumption (standby)	3 W
Power consumption (typical)	90 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (bottom)	13.2 mm
Panel mounting interface	300 x 300 mm
Sustainability certificates	RoHS, ENERGY STAR
Certification	C-tick; CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL/CSA; VCCI
RMS rated power	20 W
Cables included	AC, DVI
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPEG1, MPEG2, MPG, WMV
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	54.7 mm
Width	918 mm
Height	530.6 mm
Weight	14500 g
