NEC MultiSync UN552V User Manual

English
English−101
INPUT
INPUT MENU
DVI Selects the input signals source.
HDMI1
HDMI2
DisplayPort1
DisplayPort2
VGA (RGB/YPbPr)
VIDEO
MP
COMPUTE MODULE*
1
OPTION*
2
*
1
: This function is only available when Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module are installed. See page 98.
*
2
: This function depends on which option board you are using. This function is only available when option board is installed.
PICTURE MENU
PICTURE MODE SpectraView Engine = OFF: Predefined picture modes [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA],
[CUSTOM1], [CUSTOM2].
SpectraView Engine = ON: Five customizable Picture Mode memories [1], [2], [3], [4] or [5].
See page 47.
EMULATION
*1
3D LUT EMU. The 3D LUT (Look Up Table) is a three-dimensional table that maps colors into different color spaces.
The SpectraView Engine inside this monitor allows complex color gamuts, such as those for color printers,
to be emulated on the monitor directly. For example, this allows print previews or cinematic or color grading
effects to be performed within the monitor itself.
This feature is used with supporting software. 3D LUTs are uploaded to the monitor via application
software.
ON: Enables/Activates the 3D LUT function for the selected picture mode.
OFF: Disables/Deactivates the 3D LUT function for the selected picture mode.
Compare: In this mode, colors that lie outside the boundaries of the 3D LUT are shown in gray. It is
useful for determining out of gamut colors.
COLOR VISION EMU. Previews various typical human vision deficiencies and is useful for evaluating how people who have such
deficiencies will perceive colors.
This preview is available in types:
• P (Protanopia)
• D (Deuteranopia)
• T (Tritanopia)
Grayscale can be used for evaluating contrast legibility.
NOTE: Depending on the vision of the user, including those with color vision deficiency, there will be a
variation in how the screen’s color is seen and experienced. A simulation is used to illustrate the view of
those with a color vision deficiency. It is not their actual view. The simulation is a reproduction of those
with a strong color vision mode of type P, type D or type T. People with a slight color vision deficiency will
experience little to no difference compared to those with normal color vision.
*
1
: This function is available when [SPECTRAVIEW ENGINE] is set to [ON].

NEC MultiSync UN552V Specifications

General

Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	500 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	23 - 86 Hz
Horizontal scan range	26 - 134 kHz
Contrast ratio (typical)	1700:1
Display diagonal (metric)	138.78 cm
Active display area (W x H)	1209.63 x 680.34 mm
Operating hours (hours/days)	24/7
Maximum refresh rate	60 Hz
Annual energy consumption	328 kWh
Purpose	Universal
Orientation	Horizontal/Vertical
Product color	Black
Product design	Video wall
Placement supported	Indoor
Bezel width (bottom)	0.44 mm
Panel mounting interface	400 x 400 mm
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Audio formats supported	AAC, MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPG, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	225 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	BSMI; CE; EAC; EMC B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
Sustainability certificates	RoHS
Cables included	AC, DisplayPort, HDMI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	98.6 mm
Width	1210.5 mm
Height	681.2 mm
Weight	25800 g
