NEC MultiSync UN552V User Manual

English−14
Installing and Removing the Optional Table Top Stand
CAUTION:  • Installing and removing the stand must be done by two or more people.
• When installing the monitor stand, handle the unit with care to avoid pinching your fingers.
For installation, follow the instructions included with the stand or mounting equipment. Use only those devices recommended by
the manufacturer.
NOTE:  • ONLY use thumbscrews which are included in the monitor.
• Install the stand so the long end of the feet face forward. Use the ST-5220.
Soft cloth
Optional table top stand
Table
Prevent Tipping
CAUTION: 
When using the monitor with the optional table top stand, fasten the monitor to a wall using a cord or chain that can support
the weight of the monitor in order to prevent the monitor from falling. Fasten the cord or chain to the monitor using the provided
clamps and screws.
Screw (M4)
Cord or chain
Clamp
Screw Holes
325.9 mm
Before attaching the monitor to the wall, make sure that the wall can support the weight of the monitor.
CAUTION:  Be sure to remove the cord or chain from the wall before moving the monitor.

NEC MultiSync UN552V Specifications

General

Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	500 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	23 - 86 Hz
Horizontal scan range	26 - 134 kHz
Contrast ratio (typical)	1700:1
Display diagonal (metric)	138.78 cm
Active display area (W x H)	1209.63 x 680.34 mm
Operating hours (hours/days)	24/7
Maximum refresh rate	60 Hz
Annual energy consumption	328 kWh
Purpose	Universal
Orientation	Horizontal/Vertical
Product color	Black
Product design	Video wall
Placement supported	Indoor
Bezel width (bottom)	0.44 mm
Panel mounting interface	400 x 400 mm
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Audio formats supported	AAC, MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPG, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	225 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	BSMI; CE; EAC; EMC B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
Sustainability certificates	RoHS
Cables included	AC, DisplayPort, HDMI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	98.6 mm
Width	1210.5 mm
Height	681.2 mm
Weight	25800 g
