English
English−103
PICTURE MENU
COLOR
*2, *3
COLOR Adjusts the color saturation of the screen. Press + or - button to adjust.
COLOR TEMP Adjusts the color temperature of the entire screen. A low color temperature will result in a reddish screen.
A high color temperature will make the screen bluish. If TEMPERATURE needs further adjustment, the
individual R/G/B/ levels of the white point can be adjusted. To adjust the R/G/B levels, set [CUSTOM] as
[COLOR TEMP] selection.
NOTE: When [PROGRAMMABLE1], [PROGRAMMABLE2] or [PROGRAMMABLE3] is selected in
[GAMMA CORRECTION], this function cannot be changed.
COLOR CONTROL Adjusts the hue of the Red, Yellow, Green, Cyan, Blue and Magenta colors individually. Adjust the hue of
the specified color. For example, you can change red to yellow or purple.
HUE
*6
MP, VIDEO inputs only
Adjusts the hue for all colors with compatible video input signals. Press + or - button to adjust.
CONTRAST
*2, *3
Adjusts the image brightness in relationship to the input signal. Press + or - button to adjust.
SHARPNESS Adjusts the crispness of the image. Press + or - button to adjust.
UHD UPSCALING Controls how non-UHD signal is scaled up to achieve a high-definition effect.
ADJUST
AUTO SETUP
VGA (RGB) input only
Automatically adjusts Screen Size, H position, V position, Clock, Phase and White Level.
AUTO ADJUST
VGA (RGB) input only
[H POSITION], [V POSITION] and [PHASE] are adjusted automatically when new timing is detected.
H POSITION
VGA (RGB), VGA (YPbPr) inputs only
Controls the horizontal position of the image within the display area of the LCD.
Press + button to move right. Press - button to move left.
V POSITION
VGA (RGB), VGA (YPbPr) inputs only
Controls the vertical position of the image within the display area of the LCD.
Press + button to move up. Press - button to move down.
CLOCK
VGA (RGB) input only
Press + button to expand the width of the image on the right of the screen.
Press - button to narrow the width of the image on the left of the screen.
PHASE
VGA (RGB), VGA (YPbPr) inputs only
Adjusts the visual “noise” in the image.
H RESOLUTION
*7
VGA (RGB) input only
Adjusts the horizontal size of the image.
V RESOLUTION
*7
VGA (RGB) input only
Adjusts the vertical size of the image.
COLOR SYSTEM
VIDEO input only
The selected Color System depends on the video format of the input signal.
AUTO Automatically chooses the Color System setting based on the input signal.
NTSC Select a signal format.
PAL
SECAM
4.43 NTSC
PAL-60
INPUT RESOLUTION
VGA (RGB) input only
If there is a problem with signal detection, this function forces the monitor to display the signal at the
desired resolution. After selection, execute [AUTO SETUP] if required.
If no problem is detected, the only available option will be [AUTO].
*
2
: This function is available when [SPECTRAVIEW ENGINE] is set to [OFF].
*
3
: This function is not available when [sRGB] is selected at [PICTURE MODE].
*
6
: This function is not available for still image on the MP input.
*
7
: We recommended running [AUTO SETUP] after individually adjusting this option.
