English−8
4. Connect the supplied power cord
• The monitor should be installed close to an easily accessible power outlet.
CAUTION: • Fasten the power cord to the monitor by attaching the screw and clamp. (Recommended Fasten Force:
139 - 189 N•cm).
• Please make sure that enough power is supplied to the monitor. Please refer to the “Power Supply” in the
specification (See “UN552” on page 96 and “UN552V” on page 97).
Clamp
Screw
WARNING: • Please refer to the “Important Information” section of this user’s manual for proper selection of an
AC power cord.
• Fully insert the prongs into the power outlet socket. A loose connection may cause image instability and
may pose a fire hazard.
5. Cable information
CAUTION: Use the provided specified cables with this product so as not to interfere with radio and television reception.
For DVI, USB and mini D-Sub 15-pin, please use a shielded signal cable with ferrite core.
For HDMI, DisplayPort and D-Sub 9-pin, please use a shielded signal cable.
Use of other cables and adapters may cause interference with radio and television reception.
6. Turn on the power for the external equipment and the monitor
When connected to a computer, switch on the monitor power first.
7. Operate the attached external equipment
Select the input source for the attached equipment to show the image signal on screen.
8. Adjust the sound
Make volume adjustments when required.
9. Adjust the picture settings (See page 101)
If necessary, make adjustments to the backlight, colors, contrast, and image position in the OSD PICTURE menu.
10. Recommended Adjustments
To reduce the risk of the “Image Persistence”, please adjust the following items based on the application being used:
• [SCREEN SAVER] and [SIDE BORDER COLOR] in the [OSD PROTECT] menu (see page 116).
It is recommended that the [FAN CONTROL] setting also be checked [ON].
• [DATE & TIME] and [SCHEDULE SETTINGS] in the [OSD SCHEDULE] menu (see page 106).
To Next Page
