NEC MultiSync UN552V User Manual

English−20
M USB Ports
For the USB port information, please see “Connecting a
USB Device” on page 30.
USB1 (SENSOR): Downstream port (USB Type-A).
USB2: Upstream port (USB Type-B).
USB CM1 (2A): Power supply port.
USB CM2*
1
: Service port. Please do not connect
devices.
Media Player USB: USB storage device reader for use
with the Media Player.
*
1
: USB functionality is available when the optional Raspberry Pi Compute
Module Interface Board and Raspberry Pi Compute Module are installed.
See
page 98.
N VIDEO IN
Composite video signal input.
O LAN Port IN/OUT (RJ-45) (LAN1 (DAISY CHAIN IN)/
LAN2 (DAISY CHAIN OUT))
Connect to LAN in order to manage and control the monitor
over the network. See page 80.
NOTE: Please give priority for use to LAN1.
P AUDIO
Audio signal output from AUDIO 1/2, DisplayPort and HDMI
to an external device (stereo receiver, amplifier, etc.).
NOTE: This connector is not a Headphone terminal.
Q EXTERNAL SPEAKER TERMINAL
Audio signal output.
Red terminal is plus (+).
Black terminal is minus (-).
NOTE: This speaker terminal is for 15 W + 15 W (8 Ω)
speaker.
R Option Board Slot
Slot for installation of a Slot 2 type Option Board. See
page 15.
NOTE: Please contact your supplier for a list of compatible
Option Boards.
S Security Slot
Security and theft protection lock slot compatible with
Kensington security cables/equipment.
NOTE: For products, visit Kensington’s website.
T Rating Label
Intelligent wireless data sensor
Sensor for wireless communication to the monitor for
information and settings. See
page 88.
Option Speaker Mounting Holes
NOTE: Please contact your supplier for a list of compatible
speaker.
Optional Sensor Unit (remote control, room
light sensing and human sensing)
Receives the signal from the Remote control.
Detects the level of ambient light, allowing the monitor
to make automatic adjustments to the backlight setting,
resulting in a more comfortable viewing experience.
Do not cover this sensor.
Detects human presence in front of the monitor.
Raspberry Pi Compute Module Slot
Slot for installing a Raspberry Pi Compute Module Interface
Board and Raspberry Pi Compute Module. See page 98.
CAUTION:  Installation must be performed by a
qualified technician. Do not attempt to
install a Compute Module Interface Board
and Raspberry Pi Compute Module by
yourself.

NEC MultiSync UN552V Specifications

General

Pixel pitch	0.63 x 0.63 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	500 cd/m²
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	23 - 86 Hz
Horizontal scan range	26 - 134 kHz
Contrast ratio (typical)	1700:1
Display diagonal (metric)	138.78 cm
Active display area (W x H)	1209.63 x 680.34 mm
Operating hours (hours/days)	24/7
Maximum refresh rate	60 Hz
Annual energy consumption	328 kWh
Purpose	Universal
Orientation	Horizontal/Vertical
Product color	Black
Product design	Video wall
Placement supported	Indoor
Bezel width (bottom)	0.44 mm
Panel mounting interface	400 x 400 mm
USB ports quantity	5
DisplayPorts quantity	3
Compatible memory cards	MicroSD (TransFlash)
Ethernet LAN data rates	10, 100 Mbit/s
VGA (D-Sub) input ports	1
HDMI input ports quantity	2
Audio formats supported	AAC, MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, MPG, WMV
Power consumption (standby)	0.5 W
Power consumption (typical)	225 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	BSMI; CE; EAC; EMC B; FCC; PSB; RCM; REACH; RoHS; SASO; TÜV GS; TÜV S; UL/C-UL; VCCI
Sustainability certificates	RoHS
Cables included	AC, DisplayPort, HDMI
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	98.6 mm
Width	1210.5 mm
Height	681.2 mm
Weight	25800 g
