40
4. Using Menus
4-2. Table of adjustment menus
Menus in parentheses are menus for our service personnel. Normally, these menus cannot be used.
Main menu Submenu Description
Reference
page
Title Select “Title Memory Name” Selects the title of the signal to be projected. 41
TEST Pattern Selects the test pattern to be projected. 41
Configuration Light Setup Adjust Adjusts the light source brightness (output). 42
Lens Control Lens Position Adjusts the position of the projected screen. 42
Focus Zoom Adjusts the size and focus of the projected screen. 42
Reset (FactoryDefault) Returns the settings to their default values. Selects between preset but-
tons and titles only, LAN settings only and all settings.
-
Filter Cleaning Initializes the air filter usage time (for confirming the filter cleaning time). 43
(Fan Usage) Initializes the usage time of the fan. -
(Light Usage) Initializes the usage time of the light source. -
(Phosphor) Initializes the usage time of the phosphor. -
(Diffuser) Initializes the usage time of the diffuser. -
(Setup) Douser Setup Sets the douser open/close state. -
Panel Key Lock Locks the buttons on the projector’s control panel so that they cannot be
operated.
-
Auto Key Lock Enables or disables Auto Key Lock. -
3D Connector Sets the signal input terminal for a 3D image system (3D terminal or
GPI/O terminal).
-
Off Timer Sets the time until the projector power is turned off automatically. -
Message Sets the time to display the message indicating the air filter cleaning
cycle.
-
Silent Mode Selects whether to use the status indicator (SYSTEM / LIGHT), buzzer,
indicators on the control panel and backlight.
-
Installation (Note) (Option Slot) Configures the device installed in slot A (only when the projector is in
standby mode).
-
(Orientation) Sets the projection method and cooling fan operating mode. -
Lens Type (Note) Sets the type of lens (supports or does not support the lens memory func-
tion) attached to the projector.
43
Lens Calibrate (Note)
Performs calibration on lens that support the lens memory function (only
when the projector power is turned on).
43
Lens Center (Note) Moves the lens shift position to the center (only when the projector power
is turned on).
43
(Baudrate) Sets the PC control terminal (RS-232) data transmission speed (bps). -
(Date/Time) Sets the date and time on the projector. -
(Fan Speed Mode) Sets the cooling fan operating mode. -
(Service Adj.) (Only when the projector is in standby mode)
This is used during shadow adjustment and lens mount adjustment (focus
balance adjustment).
-
(Memory) Light The content of the selected light memory (light output power value) can
be overwritten with the current settings.
-
Lens The content of the selected lens memory can be overwritten with the cur-
rent settings.
-
(Title Setup) Preset Button Preset Button 1–16 Sets the title to be assigned to the preset buttons (<1> to <8> buttons). 44
Information Light Output Displays the light source output setting. 44
Lens Type Displays the lens type setting. 44
Preset Button Preset Button 1–16 Displays the titles which are assigned to the preset buttons (<1> to <8>
buttons).
44
Usage Displays information related to projector usage. 45
Error Code Displays the currently occurring error. 45
Version System Displays the model name and various version information about the
projector.
46
IMB Displays the vendor name and version information about the media
block (IMB).
46
IP Address System Displays the IP address of the projector. 46
Option Status Displays the link status of the device mounted in slot A and projector. 47
(Note) Requires logging into the projector with Advanced User or higher privileges.
To Next Page
