129
8. Appendix
3840×2160(Aspectratio:16:9)
unit: inch
Screen
size
Lens model name
L2K-10F1 L4K-11ZM L4K-15ZM L4K-20ZM L2K-30ZM L2K-43ZM1 L2K-55ZM1
100" 82.7 111.5–157.5 138.2–192.9 192.9–318.9 244.1–354.3 354.3–500.0 452.8–712.6
120" 102.4 134.9–189.0 166.6–232.3 228.3–381.9 295.3–429.1 429.1–602.4 547.2–858.3
150" 126.0 169.8–240.2 209.2–291.3 283.5–472.4 370.1–539.4 535.4–759.8 689.0–1078.7
200" 169.3 228.0–318.9 280.3–389.8 374.0–629.9 500.0–720.5 720.5–1015.7 921.3–1444.9
250" 212.6 286.3–401.6 351.3–488.2 464.6–783.5 626.0–905.5 901.6–1275.6 1153.5–1811.0
300" 255.9 344.6–480.3 422.3–586.6 555.1–937.0 752.0–1090.6 1086.6–1531.5 1385.8–2173.2
350" 299.2 402.8–559.1 493.3–685.0 645.7–1090.6 881.9–1271.7 1267.7–1791.3 1622.0–2539.4
400" 342.5 461.1–641.7 564.4–783.5 736.2–1248.0 1007.9–1456.7 1452.8–2047.2 1854.3–2905.5
500" 433.1 577.5–803.1 706.4–976.4 921.3–1555.1 1259.8–1822.8 1818.9–2563.0 2322.8–3637.8
600" 519.7 694.1–964.6 848.4–1173.2 1102.4–1862.2 1515.7–2192.9 2185.0–3078.7 2787.4–4366.1
800" 692.9 927.1–1287.4 1132.5–1566.9 1464.6–2480.3 2023.6–2925.2 2917.3–4110.2 3724.4–5830.7
1000" 866.1 1160.0–1610.2 1416.6–1960.6 1830.7–3098.4 2531.5–3661.4 3645.7–5141.7 4657.5–7291.3
unit: m
Screen
size
Lens model name
L2K-10F1 L4K-11ZM L4K-15ZM L4K-20ZM L2K-30ZM L2K-43ZM1 L2K-55ZM1
100" 2.1 2.8–4.0 3.5–4.9 4.9–8.1 6.2–9.0 9.0–12.7 11.5–18.1
120" 2.6 3.4–4.8 4.2–5.9 5.8–9.7 7.5–10.9 10.9–15.3 13.9–21.8
150" 3.2 4.3–6.1 5.3–7.4 7.2–12.0 9.4–13.7 13.6–19.3 17.5–27.4
200" 4.3 5.8–8.1 7.1–9.9 9.5–16.0 12.7–18.3 18.3–25.8 23.4–36.7
250" 5.4 7.3–10.2 8.9–12.4 11.8–19.9 15.9–23.0 22.9–32.4 29.3–46.0
300" 6.5 8.8–12.2 10.7–14.9 14.1–23.8 19.1–27.7 27.6–38.9 35.2–55.2
350" 7.6 10.2–14.2 12.5–17.4 16.4–27.7 22.4–32.3 32.2–45.5 41.2–64.5
400" 8.7 11.7–16.3 14.3–19.9 18.7–31.7 25.6–37.0 36.9–52.0 47.1–73.8
500" 11.0 14.7–20.4 17.9–24.8 23.4–39.5 32.0–46.3 46.2–65.1 59.0–92.4
600" 13.2 17.6–24.5 21.6–29.8 28.0–47.3 38.5–55.7 55.5–78.2 70.8–110.9
800" 17.6 23.5–32.7 28.8–39.8 37.2–63.0 51.4–74.3 74.1–104.4 94.6–148.1
1000" 22.0 29.5–40.9 36.0–49.8 46.5–78.7 64.3–93.0 92.6–130.6 118.3–185.2
TIP
• Calculationofthethrowdistancefromthescreensize
 L2K-10F1lensthrowdistance(m)=H×0.99:82.7"/2.1m(min.)to866.1"/22.0m(max.)
 L4K-11ZMlensthrowdistance(m)=H×1.33toH×1.84:111.5"/2.8m(min.)to1610.2"/40.9m(max.)
 L4K-15ZMlensthrowdistance(m)=H×1.62toH×2.24:138.2"/3.5m(min.)to1960.6"/49.8m(max.)
 L4K-20ZMlensthrowdistance(m)=H×2.11toH×3.57:192.9"/4.9m(min.)to3098.4"/78.7m(max.)
 L2K-30ZMlensthrowdistance(m)=H×2.89toH×4.19:244.1"/6.2m(min.)to3661.4"/93.0m(max.)
 L2K-43ZM1lensthrowdistance(m)=H×4.17toH×5.88:354.3"/9.0m(min.)to5141.7"/130.6m(max.)
 L2K-55ZM1lensthrowdistance(m)=H×5.33toH×8.34:452.8"/11.5m(min.)to7291.3"/185.2m(max.)
 “H”(Horizontal)referstothescreenwidth.
 *Figuresdifferbyseveral%withthetableabovebecausethecalculationisapproximate.
 Ex.:Throwdistancewhenprojectingona300"screenusingtheL4K-15ZMlens:
 Accordingtothe“Tablesofscreensizesanddimensions”incaseof3840×2160(AspectRatio16:9)(→page131),H(screen
width)=261.5"/6.64m.
 Thethrowdistanceis261.5"/6.64m×1.62to261.5"/6.64m×2.24=423.63"/10.76mto585.76"/14.87m(becauseofthezoom
lens).
