29
2. Projecting an Image (Basic Operation)
CAUTION
• Performtheadjustmentfrombehindorfromthesideoftheprojector.Adjustingfrom
thefrontcouldexposeyoureyestostronglightwhichcouldinjurethem.
• Keephandsawayfromthelensmountingportionwhilethelensshiftisinoperation.
Failuretodosocouldresultinhandsbeingpinchedbythemovinglens.
Adjustment of the projector’s settings (Level adjusters)
Theprojectormustbeplacedsquaretothescreenotherwisekeystonedistortionmayappearonthescreen.For
settingtheprojectorperpendiculartothescreenwhenviewedfromtheside,utilizingtheleveladjustersequippedat
eachcorneroftheprojectorbottom.MaximumAdjustablelengthoftheleveladjusteris10mm/0.39".
Exampleforadjustment
Raise Raise
Lower Lower
Level adjuster
NOTE:
• Donotlengtheneachoftheleveladjustersanymorethan10mm/0.39".Theforceofdoingsomaycausetheleveladjusterto
comeoff,resultingindamagetotheprojector.
• Payattentiontolengthenorshortentwoleveladjustersatfrontatthesametime.Samefortherearadjusters,otherwise,the
weightoftheprojectorisloadedononeleveladjusteranditmaycauseofdamagetoit.
