NEC NP110 - Connecting Your DVD Player with Component Output

14
2. Installation and Connections
AUDIO IN
LR
AUDIO OUT
L R
Component
YCbCr
COMPUTER IN AUDIO IN
NOTE:RefertoyourDVDplayer'sowner'smanualformoreinformationaboutyourDVDplayer'svideooutputrequirements.
Connecting Your DVD Player with Component Output
Use audio equipment for stereo sound.
The projector's built-in speaker is monaural.
DVD player
Audio Equipment
Optional 15-pin - to
- RCA (female) ×3
cable (ADP-CV1E)
Optional 15-pin - to
- RCA (female) ×3
cable (ADP-CV1E)
Component video RCA×3
cable (not supplied)
Audio cable (not supplied)
Stereo mini plug - to - RCA audio cable (not supplied)
AUDIO IN
AUDIO IN COMPUTER 1IN
COMPUTER 2 IN
NP216
