NEC NP110 - Compatible Input Signal List

80
7. Appendix
 Compatible Input Signal List
Horizontal:15KHzto100KHz(RGB:24KHzorover)
Vertical:50Hzto120Hz(Signalswithhigherthanrefreshrate85Hzsupportresolutionsof1024x768orlower.)
Signal
Resolution
(Dots)
Frequency H.
(kHz)
Refresh Rate
(Hz)
VIDEO
NTSC/PAL60 — 15.73 60.00
PAL/SECAM — 15.63 50.00
IBM compatible
640 × 480 31.47 59.94
640 × 480 31.48 59.95
640 × 480 37.86 72.81
640 × 480 37.50 75.00
640 × 480 43.27 85.01
800 × 600 35.16 56.25
800 × 600 37.88 60.32
800 × 600 48.08 72.19
800 × 600 46.88 75.00
800 × 600 53.67 85.06
1024 × 768 48.36 60.00
1024 × 768 56.48 70.07
1024 × 768 60.02 75.03
1024 × 768 68.68 85.00
1280 × 768 47.78 59.87
1280 × 800 49.70 59.81
1280 × 960 60.00 60.00
1280 × 1024 63.98 60.02
1400 × 1050 - 60.00
1600 × 1200 75.00 60.02
Apple Macintosh®
640 × 480 35.00 66.67
832 × 624 49.72 74.55
1024 × 768 60.24 74.93
HDTV
720p
1280 × 720 37.50 50.00
720p 1280 × 720 45.00 60.00
1080i 1920 × 1080 28.13 50.00
1080i 1920 × 1080 33.75 60.00
SDTV
480p — 31.47 59.94
576p — 31.25 50.00
DVD YCbCr
— 15.73 59.94
— 15.63 50.00
NOTE:
• Animagewithhigherresolutionthantheprojector’snativeresolution(NP216/NP215/NP210:1024x768/NP115/NP110:800x
600)willbedisplayedwithscalingtechnology.
• Signalsotherthanthosespeciedinthetableabovemaynotbedisplayedcorrectly.Ifthisshouldhappen,changetherefresh
rateorresolutiononyourPC.RefertoDisplayPropertieshelpsectionofyourPCforprocedures.
• SynconGreenandCompositesyncsignalsarenotsupported.
